Specification
Specifications |
2910/2910R |
2920 / 2920R |
2940 / 2940R |
---|---|---|---|
Measuring Travel |
+/- 1 mm |
+/- 1 mm |
+/- 2 mm |
Total Travel |
2.25 mm |
3 mm |
4.5 mm |
Linearity |
+/-3% (of total measuring range) |
+/- 0.3% (of total measuring range) |
+/-0.3% |
Repeatability |
0.02 m |
0.02 m |
0.02 m |
Measuring force |
0.6 N |
0.6 N |
0.6 N |
Pre-travel |
Variable |
Variable |
Variable |
Application |
Universal |
Universal |
Universal |
Environmental Protection (IEC 529) |
IP 64 |
IP 64 |
IP 64 |
Plunger guide |
Preloaded, caged linear ball bearing |
Pre-loaded, caged linear ball bearing |
Pre-loaded, caged linear ball bearing |
Cable |
2 m., Polyurethane. |
2 m (Axial) Polyurethane |
2 m (Axial) Polyurethane |
Cable support spring |
Present |
Present |
Present |
Connection adaptor |
5-pin, Male DIN plug (240 Degree C |
5-pin, Male DIN plug (240 Degree C) |
5-pin, Male DIN plug (240 Degree C) |
Total Length (with support spring) |
87 mm |
112 mm |
112 mm |
Probe Body |
Hardened and ground stainless steel (55HRC); Diameter 8h6 |
Hardened & ground stainless steel (55HRC) (Diameter 8h6) |
Hardened & ground stainless steel (55HRC) (Diameter 8h6) |
Reference temperature |
20 Degree C |
20 Degree C |
20 Degree C |
Contact Tip |
Tungsten carbide ball 3 mm Dia, M2.5 Thread. |
Tungsten Carbide Ball 3 mm Dia, M2.5 Thread |
Tungsten Carbide Ball 3 mm Dia, M2.5 Thread |
Sealing bellow |
Viton with the metal clips |
Viton with the metal clips |
Viton with the m |
